Product Manuals
Below are the comprehensive product manuals for the Smartline Medical CSSD products. In these you will find the instructions for use, maintenance information, cleaning guide and comprehensive technical data.
SmartSink Manual
User and Installation Manual for SmartSink products
SmartPack Manual
User and Installation Manual for SmartPack products
Univator Manual
User Manual for SmartLift Univator product
Washer Rack Lifter Manual
User and Installation Manual for SmartLoada Washer Rack Lifter products
Overview Technical Specifications
SmartSink
Dimensions: CUSTOM
Weight: Dependent on sink size. Average weight 150kg
Palleted Details for Freight: Pallet is 200mm longer and 200mm wider than sink unit. Usual height for freight is 1350mm
Palleted Weight: Dependent on sink size. Average weight 170kg
Power Supply: 240V / 10A (USA: 110V / 20A)
Safe Working Load: 50kg plus water in bowls
*note accessories ordered may change the above
SmartPack Tables
1400mm (10.SP-C-1480-SM)
Dimensions: 1400mmL x 800mmW
Palleted Details for Freight: Flat pack: 1600mmL x 1000mmW x 1000mmH // Assembled: 1700mmL x 1060mmW x 1000mmH
Palleted Weight: 150kg
Power Supply: 240V
Safe Working Load: 100kg
Castor Size: 100mm braked castors
1700mm (10.SP-C-1780-SM)
Dimensions: 1700mmL x 800mmW
Palleted Details for Freight: Flat pack: 1900mmL x 1000mmW x 1000mmH // Assembled: 2000mmL x 1060mmW x 1000mmH
Palleted Weight: 160kg
Power Supply: 240V
Safe Working Load: 100kg
Castor Size: 100mm braked castors
2000mm (10.SP-C-2080-SM)
Dimensions: 2000mmL x 800mmW
Palleted Details for Freight: Flat pack: 2200mmL x 1000mmW x 1000mmH // Assembled: 2300mmL x 1060mmW x 1000mmH
Palleted Weight: 170kg
Power Supply: 240V
Safe Working Load: 100kg
Castor Size: 100mm braked castors
*note accessories ordered may change the above
Product Drawing Blocks
On the below links you will find drawing blocks which can be inserted into room layouts to assist with design and site planning.
If you require a different file type, please contact the Smartline team through the contact details on the distributor portal home page.
